Product overview:
Light porcelain packing is widely used in coking plant, gas plant chemical purification tower and melamine plant as washing tower packing (such as desulfurization tower, benzene washing tower, ammonia washing tower, final cooling tower, water washing tower), and the use effect is very good. Its characteristics It is resistant to high temperature purging, low specific gravity, low resistance, large mass transfer coefficient, good absorption effect, aging resistance, strong corrosion resistance, long life, and usually does not need to be overhauled.
Product Features:
●The mass transfer effect of light porcelain packing is better than that of rosette packing.
●The light porcelain filler is not aging or deformed, and its technical index stability is better than that of rosette filler.
●The service life of the light porcelain packing is similar to that of the tower body, which is more than four times the service life of the rosette packing, so the annual investment cost of the light porcelain packing is lower than that of the rosette packing.
Product name
|
Model
|
Opposite margins
|
Accumulation gap
|
Aperture
|
Specific surface area
|
Porosity
|
Bulk weight
|
Number of stacked blocks
|
Light Porcelain Plum Wreath
|
WF-1
|
220±25
|
20
|
65
|
118
|
85
|
280
|
200
|
Seven-hole ribbed ring
|
X-1
|
220±25
|
20
|
65
|
128
|
75
|
320
|
200
|
Six Lingo ring
|
X-2
|
220±25
|
20
|
65
|
135
|
72
|
340
|
200
|
Liuling multi-rib ring
|
X-3
|
220±25
|
20
|
65
|
132
|
75
|
300
|
200
|
Rotating multi-tooth ring
|
X-4
|
220±25
|
20
|
65
|
148
|
73
|
348
|
200
|
